HOWTO_android

This document shows several examples of how to use the GFXReconstruct tools. These examples will help work through issues you may discover while attempting to perform the same process on your own application.

NOTE: Many of these examples are given based on using a Linux system as the build and/or host, but you should be able to replicate the behavior on a Windows system with very few changes.

Building Vulkan Samples with the Capture Layer

Let's look at adding the GFXReconstruct layer as a requirement of the Khronos Vulkan Samples project. These steps assume that you have installed all the appropriate dependencies necessary to build that project. Please refer to that repository to ensure these dependencies have been met before continuing.

1. Pull down the GFXReconstruct source

If you haven't already, pull down the GFXReconstruct source from GitHub so that it also updates any necessary submodules as part of the clone operation:

git clone --recurse-submodules https://github.com/LunarG/gfxreconstruct.git

The full location of the gfxreconstruct folder generated from this step is to be used in all cases below for {gfxreconstruct_root}.

2. Pull down the source for Vulkan Samples

git clone --recurse-submodules https://github.com/KhronosGroup/Vulkan-Samples.git

3. Enter the Vulkan Samples source directory

cd Vulkan-Samples

4. Build the gradle files

./bldsys/scripts/generate_android_gradle.sh

5. Edit the top-level settings.gradle file

include(':app',':VkLayer_gfxreconstruct')
project(':VkLayer_gfxreconstruct').projectDir = file('{gfxreconstruct_root}/android/layer')

NOTE: Replace {gfxreconstruct_root} with the full path location of the source you cloned from the GFXReconstruct repo in Step 1.

6. Add the capture layer to the samples application

Open ./build/android_gradle/app/build.gradle and add the following line at the top of the dependencies block at the end of the file:

implementation project(':VkLayer_gfxreconstruct')

dependencies {
    implementation project(':VkLayer_gfxreconstruct')
    implementation 'androidx.appcompat:appcompat:1.3.0'
    implementation 'com.google.android.material:material:1.4.0'
    implementation 'androidx.constraintlayout:constraintlayout:2.0.4'
}

7. Change to the appropriate build folder

From the top-level samples folder you now need to enter the following sub- folder to build

cd build/android_gradle

8. Build the appropriate target

Some common targets are assembleDebug and assembleRelease. We'll build for debug in this scenario:

gradle assembleDebug

Capturing Vulkan Samples

The example that follows uses the Khronos Vulkan Samples built above and assumes that you built the debug version. The benefit of building the application in this way is that it will automatically incorporate the GFXReconstruct capture layer into the .APK file for the built application.

1. Run Logcat

adb logcat -s gfxrecon,vulkan

2. Install the debug version with storage access

Install the debug version of the samples we just built with the -g option to request storage access:

adb install -g ./build/android_gradle/app/build/outputs/apk/debug/vulkan_samples-debug.apk

This should guarantee that the application (and any associated layers) can output anything generated.

3. Enable GFXReconstruct

Enable the GFXReconstruct layer only for the application using the global settings Android provides:

adb shell settings put global enable_gpu_debug_layers 1
adb shell settings put global gpu_debug_app com.khronos.vulkan_samples
adb shell settings put global gpu_debug_layers "VK_LAYER_LUNARG_gfxreconstruct"

4. Set the capture options

Now, set the command to capture frames 500-700 so we can see what's happening and write the file to the /sdcard/Download folder:

adb shell "setprop debug.gfxrecon.capture_file  '/sdcard/Download/samples_capture.gfxr'"
adb shell "setprop debug.gfxrecon.capture_frames '500-700'"

5. Run the application

Keep the logcat output in a separate window/terminal so you can monitor it for any useful information.

To run the application, look at the application list on the Android device, then click the Vulkan Samples application to launch. Android may ask you to "Allow access to manage all files." When asked, enable the option and click the back arrow to get to the application.

Once launched, you will see something similar to the following in the logcat window/terminal:

D vulkan  : added global layer 'VK_LAYER_LUNARG_gfxreconstruct' from library
   '/data/app/....==/com.khronos.vulkan_samples..../base.apk!/lib/arm64-v8a/libVkLayer_gfxreconstruct.so'

This message states that it found the GFXReconstruct capture layer in the base.apk file which we built earlier -- meaning there's no need to add an additional external layer to any folders.

Now, click on one of the samples. In this scenario, let's click on the "Dynamic uniform buffers" test.

gfxrecon: Finished recording graphics API capture

NOTE: If the application rendered correctly, proceed to Step 6. If the application rendered incorrectly during the capture, review the guidance below.

Running certain Vulkan samples tests results in corruption and requires additional changes to capture properly. For example, if you attempted to capture the "Instancing" sample, it will render without the asteroids. This is because the GFXReconstruct layer needs some additional settings to properly align and track the memory.

adb shell "setprop debug.gfxrecon.page_guard_persistent_memory true"

When this option is enabled, an allocation with a size equal to that of the object being mapped is made once on the first map and is not freed until the object is destroyed. Use this option with applications that frequently map and unmap large memory ranges -- avoiding frequent allocation and copy operations that can have a negative impact on performance.

adb shell "setprop debug.gfxrecon.page_guard_align_buffer_sizes true"

This option overrides the Vulkan API calls that report buffer memory properties to report that buffer sizes and alignments must be a multiple of the system page size. Use this option with applications that perform CPU writes and GPU writes/copies to different buffers that are bound to the same page of mapped memory, which may result in data being lost when copying pages from the page_guard shadow allocation to the real allocation. This data loss can result in visible corruption during capture. Forcing buffer sizes and alignments to a multiple of the system page size prevents multiple buffers from being bound to the same page, avoiding data loss from simultaneous CPU writes to the shadow allocation and GPU writes to the real allocation for different buffers bound to the same page.

6. Verify the Capture File

With adb logcat open, look at the output to determine the location to which the file was recorded. In my case, the file was recorded to /sdcard/Download. NOTE: It actually lists the full file in the message like the following:

gfxrecon: Recording graphics API capture to
         /sdcard/Download/gfxrecon_capture_frames_500_through_700_20221211T130328.gfxr

adb shell ls /sdcard/Download

gfxrecon_capture_frames_500_through_700_20221211T130328.gfxr

7. Disable The GFXReconstruct layer

We want to make sure that the layer is not present for any further work we are going to do. In this case, we're going to check our replay, so disable any active debug layers so they don't interfere with the tool.

adb shell settings put global enable_gpu_debug_layers 0
adb shell settings put global gpu_debug_layers ""

8. Install the replay application

Now, we need to install the Replay application that we built as part of the GFXReconstruct source. From the top of the source pulled down from the repo by using the gfxrecon.py script:

./android/scripts/gfxrecon.py install-apk android/tools/replay/build/outputs/apk/debug/replay-debug.apk

Additional Permissions

A recent change to enable the replay tool on Android 12 and greater has resulted in the need of enabling additional permissions on some versions of Android. This was the result of updating the replay's Android Manifest file to add the MANAGE_EXTERNAL_STORAGE permission flag.

Android 10

For replay devices running Android 10, the replay tool now requires the enabling of legacy storage access:

adb shell appops set com.lunarg.gfxreconstruct.replay android:legacy_storage allow

Android 11 and Newer

For replay devices running Android 11 and newer, the replay tool requires that the Android permission for MANAGE_EXTERNAL_STORAGE be granted either through the following adb command or by clicking on the permission dialog when it opens up:

adb shell appops set com.lunarg.gfxreconstruct.replay MANAGE_EXTERNAL_STORAGE allow

9. Run the replay

./android/scripts/gfxrecon.py \
    replay /sdcard/Download/gfxrecon_capture_frames_500_through_700_20221211T130328.gfxr

10. Pull down the replay if needed

If you need to share your replay file, make sure to pull it off of the device for sharing:

adb pull /sdcard/Download/gfxrecon_capture_frames_500_through_700_20221211T130328.gfxr

Capturing Released Application On Rooted System

In this example, we'll capture a set of frames from the GPUScore benchmark. This set of instructions assume that you have already properly rooted your device, reinstalled the correct Android image, and installed the target application (in this case the benchmark).

1. Create an ADB shell with admin capabilities

adb shell
su

2. Find out full name of application

adb logcat -s vulkan

In my case, I see that the full application name is com.basemark.gpuscore.sacredpath.

adb shell cmd package list packages -3

3. Find out path for data

find /data/app -name *${Full Application Name}*

On my system, running find /data/app -name *com.basemark.gpuscore.sacredpath* returned:

/data/app/~~CklMw7KUY3NvpJa1VxdzCg==/com.basemark.gpuscore.sacredpath-y4DeeR7lnUlvifTr1xSRWA==

4. Copy over the GFXReconstruct capture layer

In another terminal/command window, change directory to the location of your GFXReconstruct source. After building, perform the following command:

adb push \
    ./android/layer/build/intermediates/cmake/debug/obj/arm64-v8a/libVkLayer_gfxreconstruct.so \
    /storage/emulated/0/Download

Now, copy it into the application folder discovered in step 3 above using the admin ADB shell:

mv /storage/emulated/0/Download/libVkLayer_gfxreconstruct.so \
       ${Application Data Path}/lib/arm64/libVkLayer_gfxreconstruct.so

chmod 777 ${Application Data Path}/libVkLayer_gfxreconstruct.so

5. Enable the layer for capture

Several differences versus the non-rooted path include: * You must enable the layer system wide in this configuration * You need to disable the Vulkan usage for the UI or it would interfere with the capture:

adb shell "setprop debug.vulkan.layers 'VK_LAYER_LUNARG_gfxreconstruct'"
adb shell "setprop debug.hwui.renderer 'skiagl'"

6. Set GFXReconstruct capture options

adb shell "setprop debug.gfxrecon.capture_frames '100-200'"

adb shell "setprop debug.gfxrecon.capture_file /storage/emulated/0/Download/sacredpath_capture.gfxr"

adb shell "setprop debug.gfxrecon.page_guard_persistent_memory true"

When this option is enabled, an allocation with a size equal to that of the object being mapped is made once on the first map and is not freed until the object is destroyed. This option is intended to be used with applications that frequently map and unmap large memory ranges, to avoid frequent allocation and copy operations that can have a negative impact on performance.

adb shell "setprop debug.gfxrecon.page_guard_align_buffer_sizes true"

This option overrides the Vulkan API calls that report buffer memory properties to report that buffer sizes and alignments must be a multiple of the system page size. This option is intended to be used with applications that perform CPU writes and GPU writes/copies to different buffers that are bound to the same page of mapped memory, which may result in data being lost when copying pages from the page_guard shadow allocation to the real allocation. This data loss can result in visible corruption during capture. Forcing buffer sizes and alignments to a multiple of the system page size prevents multiple buffers from being bound to the same page, avoiding data loss from simultaneous CPU writes to the shadow allocation and GPU writes to the real allocation for different buffers bound to the same page.

7. Give the application permission to write

adb shell pm grant com.basemark.gpuscore.sacredpath android.permission.WRITE_EXTERNAL_STORAGE

8. Run the application

In my case, I opened up the menu, found the GPUScore application and chose the official "Sacred Path" benchmark.

Watching the log output in the above adb logcat terminal, I waited until the benchmark completed and then exited the application.

I gfxrecon: Recording graphics API capture to
            /storage/emulated/0/Download/sacredpath_capture_frames_100_through_200_20221215T174939.gfxr

9. Verify the capture file

adb shell ls /storage/emulated/0/Download/sacredpath_capture_frames*.gfxr

10. Disable the capture layer

Disable the capture layer globally and also restore the Vulkan usage of the HWUI:

adb shell "setprop debug.vulkan.layers ''"
adb shell "setprop debug.hwui.renderer 'skiavk'"

11. Install the replay application

Now, we need to install the Replay application that we built as part of the GFXReconstruct source. Install the replay APK from the root of the built source tree by using the gfxrecon.py script:

./android/scripts/gfxrecon.py install-apk android/tools/replay/build/outputs/apk/debug/replay-debug.apk

12. Run the replay

./android/scripts/gfxrecon.py replay \
  /storage/emulated/0/Download/sacredpath_capture_frames_100_through_200_20221215T174939.gfxr

NOTE: Please refer to Additional Permissions above for additional permissions that may need to be enabled to run the replay application on certain versions of Android.
